Features & Specifications
|
AMPLIFIER SPECS
|
Power Output (All channels) |
100 W per channel @ 8 Ω (20 Hz–20 kHz, 0.08 % THD, 2-ch driven) |
Dynamic Power |
210 W @ 6 Ω (1 kHz, 10 % THD) |
VIDEO & HDMI FEATURES
|
HDMI Connectivity |
6 inputs (x1–3 support 8K/60 & 4K/120), 2 outputs (Main & Sub/Zone 2) with HDMI 2.1, eARC, VRR, ALLM, QFT, QMS, DSC |
HDR & Video Formats |
Dolby Vision, HDR10, HDR10+, HLG, BT.2020, HDCP 2.3 |
AUDIO FORMATS & PROCESSING
|
3D & Surround Sound |
Dolby Atmos, DTS:X, Dolby Atmos Height Virtualizer, DTS Virtual:X, DTS Neural:X upmix, Dolby Surround, DTS HD Master Audio |
THX & Game Modes |
THX® Select2 certified; Game Sound Modes (Rock, Sports, Action, RPG), AccuReflex for Atmos phase alignment |
NETWORK & STREAMING
|
Streaming & Multi-Room |
Wi-Fi (802.11ac 2x2), Bluetooth (Tx/Rx), Chromecast, AirPlay 2, Works with Sonos, DTS Play-Fi, Spotify, TIDAL, Amazon Music HD, Deezer, TuneIn |
ZONE & OTHER CONNECTIVITY
|
Zone 2 / Zone B Capability |
5.2 main + powered Zone 2; RCA line-out for Zone 2/Zone B analog; synced or independent playback |
Inputs |
Optical 1, Coaxial 1, Stereo RCA x4, Phono MM, USB-A (front), FM/AM tuner |
SOUND CALIBRATION & ENHANCEMENTS
|
Room Calibration |
AccuEQ: auto-detects speaker size, distance, crossover & EQs; AccuReflex for Atmos alignment |
Vocal Enhancer |
DSP-based enhancement to clarify dialogue at low volumes |
PHYSICAL & POWER
|
Dimensions (W × H × D) |
435 × 173.5 × 379.5 mm (17 1/8″ × 6 13/16″ × 14 15/16″) |
Weight |
9.8 kg (21.6 lb) |
Power Consumption |
635 W (Operating), 65 W (Idle), 0.1 W (Standby) |
